MACURCO   DVP-120

SKU# (640)



MACURCO DVP-120

GAS DETECTION CONTROLLERS / MULTI-POINT CONTROLLERS
12-CHANNEL LOW COST

$1,302.82  [2 Days]
  • DESCRIPTION
  • FEATURES
  • SPECIFICATIONS
  • LITERATURE
Macurco DVP-120 control panel features 12 sensor inputs, three 10 amp output relays, horn and strobe drivers, Internal 90 dbA buzzer, NEMA1 enclosure, and status LEDs. Compatible with MACURCO fixed gas transducers CM-6, GD-6, TX-6, OX-6, CM-2B, CM-3, CM-4, ND-2 and GT-11A over 4-20mA current loops. 90 – 250 VAC. Multi-Channel controller and alarm center for natural gas, methane, propane, hydrogen, carbon monoxide, ammonia, nitrogen dioxide and hydrogen sulfide. Optional LADBS approval.

DVP-120
1,302.82

LADBS Sticker
LADBS detectors require Macurco DVP-120 LADBS alarm panels

  [  2 Days  ]
Features
  • 12 sensor inputs
  • Three 10 amp relays
  • Horn/strobe drivers
  • Internal buzzer
  • Lockable enclosure
  • Digital display, LEDs
  • ETL Listed
Applications

Parking garages, loading docks, vehicle repair facilities, arenas, warehouses and other commercial applications

Mode: System
Area: 60,000 ft2 (5,580 m2)

Building codes require that enclosed parking garages, warehouses and vehicle maintenance facilities either have exhaust fans operate continuously, or have automatic Carbon Monoxide (CO) detection and exhaust fan control systems. The difference in fan operating time is 24 hours a day versus one to two hours. Energy savings are significant.

The DVP-120 exhaust fan controller which, in conjunction with CM-2B or CM-3 Carbon Monoxide detectors or ND-2 Nitrogen Dioxide detectors or GT-11A Combustible detectors, provide automatic controls to ensure a safe environment in parking garages or maintenance facilities. The DVP-120 can control up to twelve CO, NO or EX sensors in any combination.

The DVP-120 system is designed to meet all known specifications for safety in enclosed parking garages, including the Uniform Building Code and OSHA 50 ppm CO requirements.

MORE FEATURES
  • MONEY saving devices, both in energy costs and extended fan life.
  • Clearly labelled Modular Connectors for easy hook up.
  • Conduit holes already provided.
  • Flexible configuration to meet any application.
  • Each DVP-120 can control up to three zones.
  • Fan settings are end user adjustable, to meet any specification.
  • Driver circuits provided for horn and strobe alarm signals.
  • Bright LEDs indicate system status including alarm and relay status.
  • All Sensors are supervised; panel LCD indicates sensor status and individual gas levels.
  • Lockable Nema 1 type enclosure.
  • No regular maintenance necessary.
  • Simple installation and operation.
DVP-120 Inside

DVP-120 Specifications
Size 10 x 12 x 2 inches
Shipping Weight 6.5 poundS
Power Input 100 - 240 VAC 1 amps
Output Control Relays 3
Relay Rating 16 amps / 240 volts
CO Transducer Range 0 - 250 ppm
NO Transducer Range 0 - 9 ppm
EX Transducer Range 0 - 10000 ppm
Relay Turn On Delay 0 - 15 minutes
Relay Turn Off Delay 0 - 15 minutes
Export Info
Harmonized Tariff Code (HTC)8531100045

 Info/Quote Request
 Reseller & Volume Discounts
 Shipping Rates

B2B Checkout Options: Designated Carrier and Tax-Exempt purchase
Payment Options: Credit Card, Credit Card Over the Phone, PAYPAL, Wire Transfer and Check

Checkout with Paypal Visa MasterCard Amex Checkout with Wire Transfer Electronic Payment
